Gabatarwar Samfur
Cikakken Maganinmu na Silant & Tef ɗin Module PV yana wakiltar "tsarin tsaro" mai mahimmanci ga modules na photovoltaic, yana tabbatar da dogaron dogon lokaci fiye da shekaru 25. Waɗannan kayan taimako da ake ganin ƙanana amma masu mahimmanci suna samar da shinge masu yawa na kariya daga ƙalubalen muhalli. Layin samfuranmu ya haɗa da silant na silicone mai inganci don firam da akwatin haɗin wutar lantarki hatimi, tare da tef na musamman don rufi, gyarawa, da aikace-aikacen hatimin gefe.
A matsayin babban mai samarwa ta hanyar Ooitech (www.ooitech.com), muna ba da kayan rufewa da rufewa na masana'antu waɗanda aka tsara musamman don kera hasken rana. Waɗannan samfuran sune mahimman abubuwa a cikin cikakken layin samar da hasken rana, daga 5MW zuwa 1GW, suna tabbatar da ingantaccen aiki da tsawon rai a yanayin filin mai wahala.
Technical Specifications
Ƙayyadaddun Maganin Rufe
| Parameter | Ƙayyadaddun Bayanai | Daidaitacce |
|---|
| Nau'in Kayan | Silicone Cure Neutral | Mai yarda da IEC 61215 |
| Zazzabi Aiki | -40°C zuwa +85°C | ASTM C1184 |
| Juriya UV | >25 shekaru | ISO 4892-3 |
| Ƙarfin Juriya | ≥1.8 MPa | ASTM D412 |
| Tsawon Lokacin Karya | ≥400% | ASTM D412 |
| Taurin Shore A | 25-35 | ASTM C661 |
| Lokacin Warkarwa (Ba tare da mannewa ba) | 10-30 mintuna | @ 23°C, 50% RH |
| Cikakken Lokacin Warkarwa | 24-72 hours | @ 23°C, 50% RH |
| Ƙarfin Dielectric | >20 kV/mm | ASTM D149 |
| Watsawar Tururin Ruwa | <5 g/m²/rana | ASTM E96 |
Ƙayyadaddun Tef na Musamman
| Nau'in Tef | Abu | Kauri | Mannewa | Ƙarfin Dielectric |
|---|
| Rufin Haɗin Giciye | Fim ɗin PET | 0.05-0.1mm | >8 N/25mm | >6 kV |
| Rufe Gefen | Butyl Rubber | 1-2mm | >15 N/25mm | >5 kV |
| Gyaran Busbar | Acrylic/PET | 0.1-0.2mm | >10 N/25mm | >4 kV |
| Hawan Frame | PE Foam | 1-3mm | >12 N/25mm | >3 kV |
Fa'idodin Fasaha
Kariya Mafi Girma Daga Danshi da Muhalli
Cikakken Rashin Shiga Ruwa: Yana samar da shinge cikakke daga shigar ruwa, danshi, da ƙura
Hana Rushewa Ta Hanyar Ruwa: Yana kare EVA/POE encapsulantdaga lalacewa
Juriya ga Lalacewa: Yana hana lalacewar lantarki da gajerun hanyoyi na ciki
Kariya Mai Yawa: Haɗin kai da tsarin tef yana ba da kariya mai yawa
Kyakkyawan Aiki na Injiniya
Sassauci na Dindindin: Yana kiyaye elasticity a duk tsawon shekaru 25+ na sabis
Shaƙar Damuwa na Zafi: Yana ɗaukar faɗaɗa daban-daban tsakanin gilashi, ƙarfe, da kayan polymer
Damping na Girgiza: Yana rage damuwa na injiniya daga iska da hawan zafi
Manaƙa Mai Ƙarfi: Yana tabbatar da haɗin kai na dindindin ba tare da buƙatar primer ba
Juriya na Yanayi na Musamman
Tsayayyen UV: Babu lalacewa a ƙarƙashin ci gaba da hasken rana
Hawan Zafi: Yana aiki da aminci daga -40°C zuwa +85°C
Juriya na Sinadarai: Yana jure ruwan acid, hazo na gishiri, da gurɓataccen masana'antu
Dogaro na Dogon Lokaci: Aikin filin da aka tabbatar ya wuce shekaru 25
Amfanin Inganta Aiki
Saurin Lokacin Bushewa: Yana ba da damar saurin samar da kayayyaki
Sauƙin Aiwatarwa: Yana dacewa da tsarin rarraba kai tsaye
Daidaiton Inganci: Abubuwan da suka dace daga kashi zuwa kashi
Mai Raha: Yana rage da'awar garanti da gazawar filin
Aikace-aikacen Samfur
Aikace-aikacen Rufe Frames
An tsara silicone sealants ɗinmu musamman don mu'amala mai mahimmanci tsakanin aluminum frames da gilashin laminates. Wannan aikace-aikacen yana hana shigar danshi a gefen module, wanda shine babban wurin gazawa a shigarwa a filin. Sealant ɗin yana haifar da haɗi na dindindin, mai sassauƙa wanda ke ɗaukar motsi na zafi yayin da yake kiyaye cikakken keɓewar muhalli.
Hawan Akwatin Junction
Haɗin akwatin haɗin wuta-zuwa-backsheet yana buƙatar mannewa da kaddarorin hatimi na musamman. Silant ɗinmu suna tabbatar da kariya mai darajar IP67/IP68, suna hana shigar ruwa wanda zai iya haifar da gazawar lantarki. Kaddarorin dielectric na kayan suna ba da ƙarin amincin rufi, mai mahimmanci ga ƙirar module mai ƙarfin lantarki ciki har da tsarin 1500V.
Rufin Haɗin Giciye
Tef ɗin rufi na tushen PET suna hana gajerun lantarki a wuraren tsallakewar igiyar tantanin halitta. Muhimmi ga ƙirar rabin tantanin halitta da tantanin halitta mai shinge, waɗannan tef ɗin suna kiyaye ƙarfin dielectric ɗinsu ko da a ƙarƙashin yanayin zafi da matsi na lamination. Sun dace da duk fasahar tantanin halitta ciki har da PERC, TOPCon, IBC, da tsarin HJT.
Tsarin Rufe Gefen
Tef ɗin gefen butyl roba suna ba da kariyar danshi na farko, musamman mahimmanci ga ƙirar maras firam da dual-glass. Waɗannan tef ɗin suna ba da hatimi nan da nan bayan shafa, suna haifar da shingen hana tururi wanda ke haɗawa da tsarin hatimin firam. An gwada su sosai don dacewa da duk manyan nau'ikan backsheet da gilashi.
Haɗin Layin Samarwa
Duk samfuran an inganta su don haɗawa da cikakkun layukan samar da hasken rana na Ooitech, gami da tsarin rarraba atomatik akan injin firams da tashoshin shafa tef. Ya dace da tsarin tantanin halitta M6, M10, M12 da fasahar haɗin MBB.
Tuntuɓi don Siyayya
Samun Maganin Rufe Hasken Rana na Kwararru daga Ooitech
Tabbatar da samar da hasken rana na ku yana samun ingantaccen aiki tare da maganin rufewa da tef na masana'antar mu. A matsayin wani ɓangare na kayan aiki da kayan samar da hasken rana na Ooitech, muna ba da cikakken tallafin fasaha daga zaɓin kayan aiki zuwa aiwatar da samarwa.
Zazzage Albarkatun Fasaha:
Kalli Bidiyon Layin Samar da Mu:
Biyan tashar mu ta YouTube don ƙarin fahimta game da fasahohin samar da hasken rana da kyawawan ayyuka.
Tuntuɓi Ƙungiyar Fasaha ta Mu:
Imel: [email protected]
Lambar waya: +86 18571646990
WhatsApp: +86 15961592660
Babban Ofishin: Wuhan Yangtze River Center, Wuhan, China
Gidan Yanar Gizo: www.ooitech.com
Nemi Farashi a Yau! Kwararrun fasaha na mu za su taimaka muku zaɓar mafi kyawun kayan rufewa da rufewa don ƙirar tsarin ku da buƙatun samarwa. Muna ba da fakiti cikakke waɗanda suka haɗa da kayan aiki, kayan aiki, horo, da tallafin fasaha na ci gaba.
